WINTER IS COMMING! METEOR65 IS READY!
The TBS Crossfire Nano receiver with minimal T Crossfire antenna is available on Meteor series for all CRSF user. This specific variation is only designed to be small, light, and easy to use.
This antenna is designed by Michael Anderson, produced by FPVCycle and manufactured by TBS. Know more about this antenna.
The performance of 65mm 1S brushless drone has gone up a new level this winter. What is your exception for this drone? Aggressive power and faster speed, or longer flying time? Here is the comparison of different motors.
Thanks for the feedback and advice from Nate Payne and Michael Huddleson. You could choose the Meteor65 Version above. Also, you could get the spare motors if want to try both.
Meteor65, a leading 1S whoop WINTER TIME drone. It’s equipped with the BT2.0 connector, lightest F4 1S FC and 0802 19500/22000KV motors. With the stronger and powerful dynamical system, you’ll immediately notice how fantastic the 22.84g Meteor racer is at takeoff. It feels amazing as you hover around indoor, then let it rip and haul around the house!
Specification
- Item: Meteor65 1S Brushless Whoop
- Weight: 22.84g (without battery)
- FC&ESC: F4 1S Brushless Flight Controller V2.1
- Frame: Meteor65 65mm 1S Brushless Frame
- Motors: 0802 19500 / 22000KV Motors
- Props: 31mm 3-blade props (1.0mm Shaft)
- VTX&Camera: M01 AIO Camera VTX
- Receiver Option: Frsky XM / DSMX / Futaba S-FHSS / TBS Crossfire
- Battery: BT2.0 300mah 1S Battery
- Flight time: 0802 19500KV motor version: 3:30min-4min / 0802 22000KV motor version: 1:30min-2min
Flight Controller
F4 1S brushless FC V2.1– This is the lightest FC in the current market. It has a
slim and sleek design, weighs just 2.69g and performs better giving it maximum weight savings, power, and responsiveness.
SPECIFICATIONS OF FC & ESC
- CPU: STM32F411CEU6 ( 100MHZ )
- Six-Axis: MPU-6000 triaxial accelerometer / triaxial gyroscope (SPI connection)
- Firmware version: Betaflight MATEKF411RX (MK41R)
- OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
- Current: 5A continuous and peak 6A (3 seconds)
- Support BLHeliSuite programmable
- Factory firmware: O_L_5_REV16_6.HEX
Camera & VTX
M01 AIO Camera VTX– The unit is ultra-lightweight only 3g, perfect for Meteor65. It comes with a super Mini 5.8GHz FPV Transmitter + 600TVL FPV Camera + RG178 Antenna, features 6 bands and 48 channels on the 5.8GHz band with Raceband.
Motors
0802 19500 / 22000KV motors using ball bearing instead of brass bushings, and PCB connector. More durable and easier to repair once disconnection.
Frame
The lightest lower profile 65mm frame- Meteor65 frame is reduced 0.75g
to 3.14g only. The battery slot is closer to the center of gravity for a
smoother flying experience, and you will land on the motor screws instead of the battery. There are more options for colorful frames such as Beta-blue, mint-green, sakura-pink, mango-orange, etc.
Package
- 1 * Meteor65 Brushless Whoop Quadcopter (1S)
- 1 * 300mAh 1S 30C Battery with BT2.0 connector
- 1 * BT2.0-PH2.0 Adapter cable
- 1 * Spare camera mount with 25° tilt
